Manufacturer Direct Sale 7/16 Din Male to 4.3-10 Mini Din 1/2' Super Flexible Jumper Cable
Overview
1/2" RF Feeder Cable / Corrugated Cable/ Andrew Heliax Cable 1/2" RF feeder cable, 50Ohm, also be named as half inch coaxial cable, has pretty good performances, wish loss, great attenuation and PIM. Its assemblies usually fixed with N type connectors. This 1/2" RF feeder cable and its assemblies are largely used on various antennas, cellphone/mobile phone signal boosters, repeaters. It's also suitable for GSM,CDMA ,PHS ,TD-SCDMA ,CDMA2000 and WCDMA and etc.
Features
• 50 Ohm data signal transmission;
• The shielding layer composed of aluminum foil and braiding has a good shielding effectiveness;
• Excellent performance in high frequency,VSWR stability;
• RoHS compliant;
|
7/16 DIN Male to 4.3-10 Mini Din Jumper cable for HRCAY-50-9(1/2"Super Flexible) |
|||
|
Cable Type |
HRCAY-50-12(1/2" Flexible) |
||
|
Jumper Length |
3m (customization) |
||
|
Inner Conductor |
CCA (Diameter 3.60 mm) |
||
|
Dielectric |
Foam PE (Diameter 9.20mm) |
||
|
Outer Conductor |
Corrugated Copper Tube(Diameter 12.00mm) |
||
|
Jacket |
Black PE (Diameter 13.60mm) |
||
|
ConnectorA,B |
DIN Type Straight male/Mini Din type Straight male |
||
|
Inner Conductor Pin |
Brass/Silver Plating |
||
|
Body&Outer Conductor |
Brass/Trimetal Plating |
||
|
Insulator |
PTFE |
||
|
Gasket |
Silicon Rubber |
||
|
Characteristics Impedance |
50 Ohm |
||
|
Frequency Range |
DC~7.5GHz |
||
|
Insulation Resistance |
≥5000MΩ |
||
|
Voltage Between Inner And Outer Canductor |
2500V rms(DC,1Min) |
||
|
Log Mag |
@DC~3.0GHz |
≤0.15*L+0.2dB |
|
|
VSWR |
@DC~2.5GHz |
≤1.10 |
|
|
@2.5~3.0GHz |
≤1.15 |
||
|
PIM3 |
≤-155dBc |
||
|
Mechanical Shock Test Method |
MIL-STD-202, Method 213, Test Condition D |
||
|
Vibration Test Method |
MIL-STD-202, Meth. 204, Cond. A |
||
|
Temperature Range |
-40°C to +85°C |
||
